APCOSHIELD IP 3
SKU: PC03
Thermosetting Polyester powder coating offering good mechanical, corrosion, and weather resistance. Available in finishes from high gloss to matt, texture, and structure. Suitable for indoor and outdoor applications.
Polyester-based
Weather resistant
Corrosion protection
Indoor and outdoor use
Uses
Characteristics
Properties
- Architectural Components
- Furniture
- Outdoor Metal Structures
- Free-flow powder
- Matt/Semi-gloss/Gloss finish
- Electrostatic spray application
- UV resistance
| Specific Gravity | 1.4–1.7 |
| Gloss | Matt 0–30 GU |
| Adhesion | GT-0 (Passes 5B) |
| Impact Resistance | 40–120 kg-cm |
| Scratch Hardness | 2–3 kg |
| Pencil Hardness | H–2H |
| Salt Spray Resistance | 500 hrs (3 mm scribe creep) |
| Humidity Resistance | 500 hrs (No blisters) |
| Weatherability | QUV-A 500 hrs (>80% gloss retention after polish) |
| Application DFT | 50–70 µm (smooth/texture), 60–80 µm (metallic), 70–100 µm (structure) |
| Curing | 200°C for 10 min |
Version No. V01/23. Please note that this datasheet supersedes all
previous versions
